Claber Hydro-4 Programmable Bluetooth Valve Boxes
4-valve irrigation controller | App programmable via Bluetooth® | IP68 fully waterproof
The Claber Hydro-4 Bluetooth® Valve Box is a compact, ready-to-use solution for managing irrigation in residential gardens. This watertight valve box houses a battery-powered controller and four solenoid valves, offering full control of underground or drip irrigation systems via the myClaber app (iOS and Android) using Bluetooth® technology.
Designed for flexibility, the Hydro-4 can be buried or installed above ground with minimal effort. Each outlet is programmable with up to 2 independent programmes and a maximum of 8 watering cycles per day. Watering durations can be set from 1 minute to 2 hours, and weekly scheduling allows the exclusion of individual days. The manual function (default 15 minutes, adjustable up to 120 minutes) enables immediate activation of watering or preset programmes. The integrated Water Budget feature allows seasonal adjustment between 50% and 150% without changing programmed schedules.
Durable and reliable, the Hydro-4 features a fully sealed IP68 housing, protecting against water, dust, and moisture. Operates with 2 x AAA 1.5V alkaline batteries (not included), and can connect to the Claber Rain Sensor BT (CTS9260) for automatic rainfall override.
The Claber Hydro-4 Bluetooth® Valve Box is a compact, ready-to-use solution for managing irrigation in residential gardens. This watertight valve box houses a battery-powered controller and four solenoid valves, offering full control of underground or drip irrigation systems via the myClaber app (iOS and Android) using Bluetooth® technology.
Designed for flexibility, the Hydro-4 can be buried or installed above ground with minimal effort. Each outlet is programmable with up to 2 independent programmes and a maximum of 8 watering cycles per day. Watering durations can be set from 1 minute to 2 hours, and weekly scheduling allows the exclusion of individual days. The manual function (default 15 minutes, adjustable up to 120 minutes) enables immediate activation of watering or preset programmes. The integrated Water Budget feature allows seasonal adjustment between 50% and 150% without changing programmed schedules.
Durable and reliable, the Hydro-4 features a fully sealed IP68 housing, protecting against water, dust, and moisture. Operates with 2 x AAA 1.5V alkaline batteries (not included), and can connect to the Claber Rain Sensor BT (CTS9260) for automatic rainfall override.
Product Overview:
- Application: Automatic control of up to 4 underground irrigation zones
- Outlets: 4 independent solenoid valves
- Programming: Via myClaber app (Bluetooth®)
- Programmes: 2 per outlet, customisable
- Max Frequency: 8 watering cycles per day
- Watering Duration: 1 minute to 2 hours
- Manual Mode: 15–120 minutes adjustable
- Water Budget: 50% to 150% seasonal adjustment
- Rain Sensor: Compatible with Claber Rain Sensor BT (CTS9260)
Technical Specifications:
- Operating Pressure: 2 - 6 bar
- Line Flow Rate: 25 l/min at 2.5 bar
- Operating Temperature: +5°C to +60°C
- Power Supply: 2 x AAA 1.5V alkaline batteries (not included)
- Protection Rating: IP68 (fully sealed, submersible)
- Inlet: 1 x ¾" male
- Outlets: 4 x ¾" male
- Dimensions: Width 205mm | Height 155mm | Depth 205mm
- Warranty: 3 years
Installation:
- Insert 2 x AAA 1.5V alkaline batteries.
- Install valve box in a suitable location, buried or above ground.
- Connect pipework to the ¾" male inlet and outlet threads; cap unused outlets with supplied threaded plugs.
- Download the myClaber app and connect via Bluetooth® to configure programmes for each outlet.
- Recommended: Pair with Claber Rain Sensor BT (CTS9260) for automatic rainfall override.
Important Notes:
- Ensure operating pressure is within the specified 2–6 bar range.
- Replace batteries annually for reliable operation.
- Rain sensor sold separately.
Specification
Claber Hydro-4 BT programmable bluetooth valve box - 4 valves - ¾" BSP - male
Product Code: CTS1210
