Oase ProfiClear Guard Level Control

Oase ProfiClear Guard Level Control – Automatic Pond Top-Up System

Maintains constant water level | Complete ready-to-install set | Ideal for ponds and reservoirs

The Oase ProfiClear Guard Level Control is a complete automatic pond top-up system designed to maintain a consistent water level in ponds and reservoirs. Simple to install and low maintenance, the system automatically refills your pond when the water level drops, ensuring stable operating conditions for filtration systems and aquatic life.

This complete set includes a plug-in transformer, controller unit, conductive sensor probe, and 1" BSP male solenoid valve. The transformer converts the 240v mains supply to a safe low voltage for the controller and sensor operation. An LED status display on the controller keeps you informed of the solenoid valve’s operating state at all times.

The conductive probe is installed at the desired water level and features clearly defined MIN (REF) and MAX sensors. When the water level drops below the longer MIN and REF probes, the valve opens to allow refill water into the pond. Once the water reaches the shorter MAX probe, the valve automatically closes. A 20mm switching differential (gap between MIN and MAX probes) prevents rapid cycling, while integrated hysteresis reduces unwanted refilling caused by waves.

The sensor can be shortened to achieve a reduced switching differential down to 10mm if required. A mounting bracket for overhanging pond edges is included for flexible installation.

Important: When connecting to a mains water supply, an appropriate air gap must always be maintained to prevent backflow contamination.

---

Product Overview:

• Application: Automatic pond and reservoir water level control
• Function: Conductive level detection with automatic refill
• Switching Differential: 20mm (adjustable down to 10mm)
• Control Display: LED status indicator for valve operation
• Installation: Simple setup with included mounting bracket
• Protection Feature: Integrated switching hysteresis to prevent false triggering

---

Technical Specifications:

• Dimensions of Controller Unit: Length 140mm | Width 95mm | Height 36mm
• Sensor Voltage: 24v
• Connection: 1" BSP male
• Max Operating Pressure: 10 bar
• Switching Differential: 20mm (adjustable down to 10mm)
• Power Cable Length: 2.0m
• Sensor Cable Length: 3.0m
• Valve Cable Length: 3.0m

---

Installation Notes:

• Install the sensor probe at the desired water level using the included mounting bracket.
• Connect the solenoid valve in-line on the top-up water supply.
• Plug in the transformer to supply safe low voltage power to the controller.
• Ensure a compliant air gap is incorporated when connecting to mains water.
• Test system operation before leaving unattended.
