IN-LITE® TOUCH DIMMER
Unhide your garden with in-lite®.
The in-lite® TOUCH DIMMER is the perfect solution for dimming up to three 12v in-lite® wall, ceiling or pendant light fittings. The TOUCH DIMMER is placed in-line between the EASY-LOCK connector on the main in-lite® power cable and the light fitting(s), with a push-fit input and output. The output can be connected directly to a single light fitting, or alternatively a two-way or three-way SPLITTER can be placed on the output to connect to two or three light fittings, ensuring the wattage total does not exceed 20 watts. The distance between the EASY-LOCK and the TOUCH DIMMER can be extended up to 4m, as well as the distance between the TOUCH DIMMER (or SPLITTER) and each light fitting, which can also be extended up to 4m. To extend the cable, use the CBL-EXT extension cables.
When the line is powered, the TOUCH DIMMER can be pressed to switch between five brightness settings, from full brightness to completely turned off. This is perfect for areas where a wall switch is required, and ceiling, wall and pendant lights are commonly used, such as garden sheds or outdoor buildings. Best of all, the TOUCH DIMMER is not just compatible with the SMART system, but the standard in-lite® HUB too.
They can be easily fixed to the wall using the provided base plate, screws and wall plugs, providing a seamless and modern looking final aesthetic. The cable entry and exit directions from the TOUCH DIMMER switch can be adjusted to suit the requirements of each application.
Note: For the switch to work, the line must be turned on to allow power to reach the light fittings.
Dimensions: Ø of switch 99mm; depth of switch 32mm (approx.)
The in-lite® TOUCH DIMMER is the perfect solution for dimming up to three 12v in-lite® wall, ceiling or pendant light fittings. The TOUCH DIMMER is placed in-line between the EASY-LOCK connector on the main in-lite® power cable and the light fitting(s), with a push-fit input and output. The output can be connected directly to a single light fitting, or alternatively a two-way or three-way SPLITTER can be placed on the output to connect to two or three light fittings, ensuring the wattage total does not exceed 20 watts. The distance between the EASY-LOCK and the TOUCH DIMMER can be extended up to 4m, as well as the distance between the TOUCH DIMMER (or SPLITTER) and each light fitting, which can also be extended up to 4m. To extend the cable, use the CBL-EXT extension cables.
When the line is powered, the TOUCH DIMMER can be pressed to switch between five brightness settings, from full brightness to completely turned off. This is perfect for areas where a wall switch is required, and ceiling, wall and pendant lights are commonly used, such as garden sheds or outdoor buildings. Best of all, the TOUCH DIMMER is not just compatible with the SMART system, but the standard in-lite® HUB too.
They can be easily fixed to the wall using the provided base plate, screws and wall plugs, providing a seamless and modern looking final aesthetic. The cable entry and exit directions from the TOUCH DIMMER switch can be adjusted to suit the requirements of each application.
Note: For the switch to work, the line must be turned on to allow power to reach the light fittings.
Dimensions: Ø of switch 99mm; depth of switch 32mm (approx.)
Specification
IN-LITE® TOUCH DIMMER for wall and pendant lights
Product Code: LIN0920
Product Code: LIN0920
