IN-LITE® CC-2 Cable Connectors
The in-lite® CC-2 cable connectors are an accessory that allows two low-voltage in-lite® CBL cables to be connected together in a split cable plan.
Each CC-2 cable connector can be loaded with up to 50VA after the connection. For example, if you have placed 60VA of fixtures after the branch-off, then you must use two CC-2 connectors to create two separate branches coming off the main circuit cable.
The in-lite® CBL cables feature a ribbed edge on one of the wires and a smooth edge on the other side. When installing a CC-2 connector you must ensure that the ribbed and smooth side of the two cables to be connected are pointing in the same direction.
Each CC-2 cable connector can be loaded with up to 50VA after the connection. For example, if you have placed 60VA of fixtures after the branch-off, then you must use two CC-2 connectors to create two separate branches coming off the main circuit cable.
The in-lite® CBL cables feature a ribbed edge on one of the wires and a smooth edge on the other side. When installing a CC-2 connector you must ensure that the ribbed and smooth side of the two cables to be connected are pointing in the same direction.
IN-LITE® CC-2 cable connector - 50VA max.
Product Code: LIN0572
Product Code: LIN0572
